COLOR FISHFINDER / GPS HUMMINBIRD HELIX 7 G4 CHIRP MEGA DI

Color Fishfinder / Gps Humminbird Helix 7 G4 Chirp Mega Di

Name: COLOR FISHFINDER / GPS HUMMINBIRD HELIX 7 G4 CHIRP MEGA DI
Brand: Humminbird
SKU: 237984
Rating: 5 (1 reviews)

Read more-Product description

(1 reviews)

From 696€

Recommended retail price : €737

Pay it in 3 or 4 interest-free payments

20 days for returns

Models & specificities

Descriptive

Reviews

Models & specificities Descriptive Reviews

Models & specificities

Back to menu

Reference

Price inc VAT

Shipping

Frequency (kHz)

Pixels

Transducer

Shipping

Price inc VAT

H7G4-CMDITA-PACK

€1013.90

180/240

1024 x 600

With Transom-Mounted Transducer

€1013.90

H7G4-CMDITA

€855.90

Shipped within

24h

180/240

1024 x 600

With Transom-Mounted Transducer

Shipped within

24h

€855.90

H7G4-CMDITP

€1239.50

180/240

1024 x 600

Through hull

€1239.50

H7G4-CMDISS

€696

180/240

1024 x 600

€696

Models & specificities Descriptive Reviews

Descriptive

Back to menu

function	value
screen size	7 inches
touchscreen	no
classic 2d	yes
down view	yes
side view	no
chirp	yes
GPS	yes
bathymetry	yes
chart reader	yes
live	no
network	no

*subtleties and options may be indicated in the full description, do not hesitate to look further or ask for advice.

the new helix 7g4 series offers increased visibility with an HD screen of 1024x600 pixels. coupled with mega down imaging technology, the helix g4 provides an unprecedented level of clarity for reading bottom structure and detecting fish.

the autochart live software is pre-loaded to give users the possibility to create detailed bathymetric mapping of the bottoms. this feature now allows displaying, in addition to bathymetry, vegetation variations and bottom hardness. maps are created live on the screen as you survey.

it is compatible with humminbird lakemaster / coastmaster maps as well as navionics maps.

mega down imaging : obtain unprecedented underwater clarity with coverage up to 40 meters below your boat. you will discover new details with up to 3 times more precision than standard down imaging sonar.

dual spectrum chirp: dual spectrum offers two search methods: wide mode for maximum coverage and narrow mode for maximum detail.

autochart live: create real-time charts of your fishing spots. trace depth contours, bottom hardness and vegetation while you drive your boat, with eight hours of built-in recording time.

control keypad : access preloaded views from the menu, operated by programmable keys that allow you to use your fishfinder reliably in all conditions.

specifications
• 7" tft 256 color full-sun LCD screen.
• very high definition screen 1024x600 pixels.
• screen size x mm
• display housing size 270x138mm
• power supply : 12v
• multifunction combo chartplotter GPS / 2d fishfinder
• dual spectrum technology.
• frequencies of the dual spectrum chirp module 140-240mhz.
• peak power 4000 watts (500 w rms).
• transducer specifications : dual spectrum / narrow beam 180-240 khz & wide beam 140-200 khz / mega 1.2 mhz / 800 / 455 khz
• standard transducer : transom (sh-a110t)
• water temperature : yes
• plastic thru-hull transducer : optional (sh-b107t)
• waterproof: ipx7.
• internal WAAS GPS antenna.
• micro SD card reader.
• ability to take screenshots.

compatible with humminbird coastmaster/lakemaster navionics + charts and autochart live.

in the box:
• helix 7g4 combo display
• screen mounting bracket ref sw-mh7
• transom transducer ref sh-a110t
• transducer bracket
• 12vcc power cord
• user manual in French

optional accessories:
• ram horizontal mount for helix 7 series ref sw-vh7
• carrying case for helix 5 and 7 ref sw-rh100
• rubber protective cover for helix 7 ref sw-rh7g2
• flush mount kit ref sw-th7

power supply advice :
a 12v lead-acid battery for 12amp minimum is recommended for good autonomy. the ends of the wires at the end of the fishfinder power cable are stripped and it is necessary to adapt and obtain terminals (not supplied with the fishfinder) to connect it to the battery.

transducer installation advice :
a stainless steel seanox slide for transducer, reference 410030, 410050 and/or 410080 allows you to properly position your transducer on your boat's transom and to protect it during launches. this thus ensures the protection of your transducer when you pull your boat onto its trailer or when you approach shallow areas such as a beach or a boat ramp. you will have the possibility to precisely adjust the transducer height so that it provides the best image rendering on your fishfinder while fishing.
three versions are available for this transducer slide in 30cm/50cm and 80cm to adapt to the height of your transom.
