GPS FISHFINDER LOWRANCE ELITE FS 10 ACTIVE IMAGING 3/1

Gps Fishfinder Lowrance Elite Fs 10 Active Imaging 3/1

Name: GPS FISHFINDER LOWRANCE ELITE FS 10 ACTIVE IMAGING 3/1
Brand: Lowrance
SKU: 339609

Read more-Product description

~~€1859.50~~

Recommended retail price : €2089.90

Pay it in 3 or 4 interest-free payments

20 days for returns

Models & specificities

Descriptive

Models & specificities Descriptive

Models & specificities

Back to menu

Reference

Price inc VAT

Shipping

Frequency (kHz)

Pixels

Transducer

Shipping

Price inc VAT

000-16438-001

~~€1859.50~~

Shipped within

24h

50/83/200/455/800

1280 x 800

Avec Sonde Active Imaging 3/1

Shipped within

24h

~~€1859.50~~

000-16437-001

€1695.50

50/83/200/455/800

1280 x 800

€1695.50

Models & specificities Descriptive

Descriptive

Back to menu

Function	Value
Screen size	10-inch
Touchscreen	yes
Classic 2D	yes
Down View	yes
Side View	yes
Chirp	yes
GPS	yes
Bathymetry	yes
Chart viewer	yes
Live	yes with optional transducer
Network	yes

*details and options may be indicated in the full description, feel free to look deeper or ask for advice.

The new LOWRANCE Elite FS (Fishing System) 10 fishfinder with ACTIVE IMAGING transducer gives you access to CHIRP 2D sonar mode, HDI DownScan Imaging™ (vertical scanned view of the bottom) and SideScan Active Imaging 3-in-1 (lateral scanned view of the bottom) as well as the full range of additional detection tools including the real-time ActiveTarget transducer optional and compatibility with a wide selection of charting options, to help you make the most of every moment on the water.

The Elite Fishing System (FS) 10 with 500w power combines the capabilities of Lowrance's latest proven echo and structure detection tools with a more affordable, easier-to-use and install display. From built-in support for ActiveTarget optional and ultra-high resolution technology with Lowrance CHIRP sonar and DownScan Imaging, to compatibility with a wide choice of chart options, the Elite FS gives you all the tools you need to find and catch more fish.

Find more fish with the Lowrance Elite FS fishfinder
With the Elite FS Active Imaging 3-in-1 fishfinder, equipped with CHIRP, SideScan and DownScan technologies with FishReveal, you can see structures and covered areas with a very high level of detail and at a range still unmatched by any other bottom imaging technology. Enjoy the best of CHIRP sonar and DownScan Imaging on the same screen with FishReveal, a Lowrance-exclusive feature that makes it easy to identify fish among structures and covered areas on extremely detailed DownScan images.

A wide range of chart options
Elite FS displays include a basic worldwide basemap without details and are compatible with a wide choice of charting options, including C-MAP, Navionics and more.

Technical specifications
• 10’’ high-resolution multitouch touchscreen
• Supports transducer frequencies 50, 83, 200, 455 and 800 kHz
• Built-in wireless, NMEA 2000 and Ethernet connectivity
• Full touchscreen control of Power Pole anchors and the Ghost bow electric motor
• Full networking with Ethernet network port (requires a LOWRANCE ETHEXT Ethernet cable)
• Easy to use and install
• Compatible with ActiveTarget G1 and G2 transducers optional reference = LW000-15593-000
• Includes a basic worldwide basemap without details, and is compatible with a wide choice of chart options, including C-MAP, Navionics and more
• Compatible with C-MAP Easy Routing and Navionics Autorouting features
• On-screen real-time mapping with C-MAP Genesis Live

Optional
• Active Target transducer reference = LW000-15593-00

In the box
• Elite Fs 10’’ display unit
• Display mounting bracket and knobs
• Supplied with a plastic screen protective cover
• TRANSOM ACTIVE IMAGING 3/1 transducer black plug reference : LW000-14489-001 for the fishfinder model reference 000-16438-001
• Transducer bracket
• 12V DC power cable
• User manual in French on CD-ROM.

User manual
