FISH FINDER GPS GARMIN ECHOMAP UHD2 72SV

Fish Finder Gps Garmin Echomap Uhd2 72Sv

Name: FISH FINDER GPS GARMIN ECHOMAP UHD2 72SV
Brand: Garmin
SKU: 281238

Read more-Product description

From 953.50€

Recommended retail price : €973.90

Pay it in 3 or 4 interest-free payments

20 days for returns

Models & specificities

Descriptive

Models & specificities Descriptive

Models & specificities

Back to menu

Reference

Price inc VAT

Pixels

Transducer

Price inc VAT

010-02683-00

€953.50

800 x 400

€953.50

010-02683-01

€1229.90

800 x 400

Avec sonde GT54

€1229.90

Models & specificities Descriptive

Descriptive

Back to menu

Function	Value
Screen size	7 inches
Touch screen	yes
2D classic	yes
Down View	yes
Side View	yes
Chirp	yes
Gps	yes
Bathymetry	yes
Card reader	yes
Live	yes with optional probe
Network	yes wireless

*Subtleties and options may be indicated in the full description, don't hesitate to dig deeper or ask for advice.

Beware!! The ECHOMAP UHD2 range revolutionises everything and brings together all the new technologies and different modes on a single touch screen SVP with a resolution of Ouf in 800X400 with Ethernet network pin, WIFI mode, new VIVID colour palettes, a precise and powerful GPS with card reader, CHIRP frequencies, an NMEA 2000 socket and a quick-release screen bracket.

For the reference model 010-02683-01, it comes complete with its GT54 rear-mounted probe for 2d sonar, ClearVü and SideVü modes.

With its high resolution touch screen of 800X400 or with the help of buttons, adjust your different parameters at lightning speed.

The quick-release screen bracket is adjustable and pivoting to allow you to orient your screen as you wish.

A network pin allows you to connect the PANOPTIX probes and/or LIVESCOPE LVS32 and/or LVS34 probes for real-time images.

The WIFI mode allows you to share sonar information (2d sonar, CV, SV and waypoints) with another compatible UIHD² sonar. You can also connect your UHD² sonar wirelessly with your GARMIN FORCE electric motor.

The VIVID colour palettes are a valuable asset to help you more easily identify echoes and structures on the bottom.

The QUICKDRAW CONTOURS function allows you to create your own Bathymetric map and the ACTIVE CAPTAIN mobile application manages everything with updates as well.

GPS TRACEUR function with a simple Micro SD card reader allows you to save your GPS points and use only the detailed Garmin Navionics+ and Garmin Navionics VISION+ maps as an option.

Key points to remember
• Easy-to-use touchscreen with tactile tracer and anti-glare bright screens
• High-resolution screen for improved detail, clarity and viewing angle
• Display what's happening under your boat with traditional Garmin sonars and ClearVü™ and SideVü™ scanning sonars featuring vivid colour palettes
• Built-in Wi-Fi® connectivity allows you to share sonar, waypoints and routes wirelessly with another ECHOMAP™ UHD2 tracer
• Includes multi-band GPS, which uses multiple frequencies for better positioning accuracy, especially in areas where signals are reflected or weak
• Supports wired NMEA 2000® network connectivity
• Pair with the free and comprehensive ActiveCaptain® app on your compatible smartphone for access to OneChart™, software updates and more
• Compatible with the LiveScope™ real-time scanning sonar

Technical Characteristics
• Physical dimensions (L x H x D) 21.8 x 14.2 x 8.1 cm
• Screen size (W x H, Diagonal) 13.8 x 7.8, 15.7 cm
• Resolution 800 x 480 pixels
• Water resistance rating IPX7
• Built-in receiver Yes
• Built-in receiver Hz 10 Hz
• BlueChart® g3 and BlueChart® g3 Vision Yes
• Garmin Navionics+™ Yes
• AutoGuidage+ technology Yes, with supported maps
• Card slot 1 microSD card; maximum size 32 GB
• Waypoints 5000
• Trace points 50000
• Traces 50 recorded traces
• Sailing features Yes
• Sonar support Yes
• Traditional Yes
• ClearVü™ and SideVü™ Sonars Yes
• Sounder frequencies Traditional: Single-channel CHIRP, 50/77/83/200 kHz, L, M, H CHIRP Garmin ClearVü and SideVü: 260/455/800/1000/1200 kHz
• Number of PINs in the probe ports 12 PIN
• Wi-Fi® connectivity (local) Yes

In the box with GT54 probe for reference 010-02683-01
• ECHOMAP UHD2 (device varies depending on selection)
• GT54-TM Transducer
• Power cable
• Tilting/swiveling mount with quick-release cradle
• Protective cover
• Hardware
• Documentation

In the box without sonar for reference 010-02683-00
• ECHOMAP UHD2 (device varies depending on selection)
• Power cable
• Tilting/swiveling mount with quick-release cradle
• Protective cover
• Hardware
• Documentation

Optional Accessories
• Livescope LVS32 probe reference 010-01864-00
• Livescope LVS34 probe reference 010-02706-00

Find the best choice on Pecheur.com among the Garmin offer to find your future Garmin GPS sonar.
