| Function | Value |
|---|
| Screen size | 5 inches |
| Touchscreen | No |
| Classic 2D | Yes |
| Down view | Yes |
| Side view | No |
| CHIRP | Yes |
| GPS | Yes |
| Bathymetry | Yes |
| Chart reader | Yes |
| Live | No |
| Network | Yes, wireless |
*Subtleties and options may be mentioned in the full description; feel free to read on or ask for advice.
Warning!! The ECHOMAP UHD2 range revolutionises everything, bringing together all the latest technologies and modes on a single-button display with an impressive 800x480 resolution, Wi-Fi, the new vivid colour palettes, a precise and powerful GPS with chart reader, and CHIRP frequencies.
For reference model 010-02589-01, it is supplied complete with its GT20 transom-mount transducer for 2D sonar and ClearVü modes.
With its high-resolution 800x480 button display, you can adjust your various settings quickly and easily.
Wi-Fi mode allows you to share sonar information (2D sonar, CV and waypoints) with another compatible ECHOMAP UHD2 unit.
The vivid colour palettes are a valuable aid to help you identify echoes and bottom structures more easily.
The Quickdraw Contours feature allows you to create your own bathymetric charts and the ActiveCaptain mobile app manages everything, including updates.
GPS chartplotter function with a simple microSD card reader allows you to save your GPS waypoints and use detailed Garmin Navionics+ and Garmin Navionics Vision+ charts as optional extras.
Key points to remember
• easy-to-use button display with chartplotter and bright anti-glare screen
• high-resolution display for improved detail, clarity and viewing angle
• see what is happening under your boat with traditional Garmin sonars and ClearVü scanning sonars featuring vivid colour palettes
• built-in Wi-Fi connectivity allows you to share sonar, waypoints and routes wirelessly with another ECHOMAP UHD2 chartplotter
• includes multi-band GPS, which uses multiple frequencies for better position accuracy, especially in areas where signals are reflected or weak
• pair it with the free, full-featured ActiveCaptain app on your compatible smartphone to access the OneChart feature, software updates and much more
Technical specifications
• physical dimensions (L x H x D) 18.8 x 12.2 x 6.2 cm
• resolution 800 x 480 pixels
• water resistance rating IPX7
• built-in receiver Yes
• built-in receiver Hz 10 Hz
• BlueChart g3 and BlueChart g3 Vision Yes
• Garmin Navionics+ Yes
• card slot 1 microSD; maximum size 32 GB
• waypoints 5000
• track points 50,000
• tracks 50 recorded tracks
• sailing features Yes
• sonar support Yes
• traditional Yes
• ClearVü™ sonars Yes
• traditional sonar frequencies: single-channel CHIRP, 50/77/83/200 kHz, L, M, H CHIRP. Garmin ClearVü: 260/455/800 kHz
• number of pins in the transducer ports 4-pin
• Wi-Fi connectivity (local) Yes
In the box with GT20 transducer for reference 010-02589-01
• ECHOMAP UHD2 (the unit varies depending on selection)
• GT20-TM transducer
• power and data cable
• swivel bracket
• hardware
• documentation
In the box without transducer for reference 010-02589-00
• ECHOMAP UHD2 (the unit varies depending on selection)
• power and data cable
• swivel bracket
• hardware
• documentation
Optional accessories
• power and data cable reference 010-12199-04
• screen protector reference 010-13116-00 supplier: Garmin France SAS
