TRANSDUCER POLE PIKE'N BASS LIVE BASIC FOR LIVE TRANSDUCERS

Transducer Pole Pike'n Bass Live Basic For Live Transducers

Name: TRANSDUCER POLE PIKE N BASS LIVE BASIC FOR LIVE TRANSDUCERS
Brand: Pike'n Bass
SKU: 356420
Rating: 3.5 (2 reviews)

Read more-Product description

(2 reviews)

From £125.47

Recommended retail price : £128.91

20 days for returns

Receive our offers and promo codes by email
Subscribe to the newsletter

Models & specificities

Descriptive

Reviews

Models & specificities Descriptive Reviews

Models & specificities

Back to menu

Reference

Price inc VAT

Model

Ø (mm)

Length (cm)

Price inc VAT

410190

£125.47

Balcony mount 30mm

100

£125.47

410191

£146.11

With pedestal

100

£146.11

Models & specificities Descriptive Reviews

Descriptive

Back to menu

The company AMIAUD continues to innovate and now offers the new LIVE BASIC transducer pole adapted for use with so-called LIVE transducers (Garmin Panoptix, Livescope, Humminbird MEGALIVE1 and 2, Lowrance Active Target…).

This new sonar technology makes it possible to use approaches such as sharpshooting, vertical or linear cast-and-retrieve in freshwater, for example, or for livebait or Broumé fishing for sea use, and gives anglers new information previously unknown about fish behavior. Fishing becomes more effective and more enjoyable but requires specific setups to be able to adjust the transducer and orient it 360°.

The LIVE BASIC transducer pole Pike'N Bass is offered in two versions:

A first version 410190 supplied WITHOUT pedestal and with a balcony-type mount of 30mm diameter adjustable in vertical and/or horizontal position.
It will still be possible to use a reducer for 25mm diameters with the reducer reference 410192.

The second version 410191 is delivered with a black Alu Pedestal reference 410188 which allows you to securely install the pole wherever you want on your boat.

Made of aluminum tubes, it adapts to all boat decks of polyester, aluminum, wood or polyethylene. The brass inserts 247316 247306 and stainless 247406 AMIAUD as Option make installation easier. It allows a rapid deployment of your transducer and a 360° orientation to optimize the view on your screen in all circumstances.

It folds easily into the horizontal position to allow you to leave your complete installation safely on your boat during high-speed navigation but also on the road during your travels.

Robust, stable and compatible with many types of installations. The live basic transducer pole is a product that allows you to equip yourself economically for a first approach to the technique.

Technical characteristics :
• Construction in anodized aluminum tube Ø30mm, robust and lightweight
• Compatible with pedestals ref. 410188 and 410174 (not included)
• Overall footprint: 1 meter
• Supplied unassembled

This product Made in France was conceived by the AMIAUD design office in collaboration with testers, anglers and professionals from the major electronics brands.

POLE CHARACTERISTICS 410190
• Aluminum tube GRAY
• Balcony mounting type (fits on pedestal 410188 and/or 410174)
• Simple, quick and effective installation
• Deployed length 1m for reference 410190 Overall length 1.00m

POLE CHARACTERISTICS 410191
• Aluminum tube ALU GRAY
• Pedestal mounting ref 410188 ALU supplied as standard: height 154mm
• Simple, quick and effective installation
• Deployed length 1m for reference 410190 Overall length 1.00m

Mounting accessories as Option for pedestal 410188
• Brass inserts M6 X4 With self-drilling screw Ref 247316
• Brass inserts M6 X4 With screw Ref 247306
• Stainless inserts M6 X2 Without screw Ref 247406

Mounting options
• Directly on the gunwale thanks to the ALU pedestal ref 410188 supplied as standard on reference 410191 height 154mm. (compatible with pedestal 410174)
• Direct on 30mm balcony.
• On 25mm balcony with the reducer as Option reference 410192
• On tubes diameter 22 to 65mm thanks to SEANOX clamps as Option ref 450425 450435 450455
• On Crosses 30° as Option ref 410171.
• On Crosses 90° as Option ref 410173.
• On rail support 90° ref 410181.
• On Lund rail support 42° ref 410182.
• On clamp ref 410179

Optional Accessories :
• Long adjustable handle for transducer pole Ref 410180
• Sight for LIVE transducer pole Ref 410183
• End stop ring Ref 410175
• GM plate transducer support transom Ref 410165
- 25mm diameter reducer as Option reference 410192

For mounting the LIVE transducer bracket of the EAGLE EYE transducer on the bottom of the tube, it is recommended to install as an Option the large model plate reference 41065 and/or 410172.

Made in France(EN)
