Specifications of the F15FWL internal combustion engine - 15 CV :
They are robust and dynamic engines, whose quality exceeds the standards required by CE and EPA regulations. All PARSUN outboard motors are subject to factory quality checks to ensure perfect mechanical operation and to give our distributors and users the assurance of having one of the best 4-stroke outboard engines on the market.

• Long shaft
• Remote throttle control
• Overall length : 643 mm
• Overall width : 369 mm
• Overall height : 1207 mm
• Recommended transom height : 508 mm
• Weight : 53 kg
• Revs : 4500-6500 tr/min
• Power [kw (Cv) @ tr/min] : 11(15)@5000
• Engine type : OHC
• Number of cylinder(s) : 2 inline
• Displacement : 323 cm³
• Bore x stroke : 59 x 59 mm
• Ignition system : CDI
• Starting system : Electric
• Positions : Forward-Neutral-Reverse
• Gear ratio : 2.08 : 1 (27/13)
• Tilt : Manual adjustment
• Fuel tank capacity : 24 L (Integrated)
• Max. consumption : 5.3 L/h
• Oil sump capacity : 1.0 L
• Oil capacity in the lower unit : 25 Cl
• Three-blade propeller : diam. x pitch [inches] : 3-9 ¼" x 11"

In the pack :
- 24 L tank
- Fuel hose and primer bulb
- Spare starter rope and handle
- Kill switch lanyard
- User manual in French
- Single lever throttle with electric start
- Throttle cable
- Forward - reverse control cable
- 2 ignition keys

Parsun engines are supplied :
- Without engine oil : the customer must fill it (oil type : SAE10W30 or SAE10W40)
- With oil in the lower unit used for storage : this must be drained, the oil to purchase is a Hypoid SAE 90 oil
The fuel to use must be 98 unleaded gasoline.
